ROHN Products, LLC -  25G size 12" Guyed Tower Kits

2010 Pricing

Posted 1/14/2010


ROHN 20 and 25 G Price List


25 G Section Numbers, Parts and Accessories Wt. (lbs) Price (ea)
R-25G EA 25G STANDARD SECTION, 10'-0" 36.80  $           135.00
R-25G7 EA 25G SECTION, 7'-0" 28.00  $           319.00
R-25AG EA 25G TOP SECTION 59.20  $           216.00
R-25AG1 EA 25G TOP SECTION 34.40  $           239.00
R-25AG2 EA 25G TOP SECTION 37.00  $           218.00
R-25AG3 EA 25G TOP SECTION 37.00  $           275.00
R-25AG4 EA 25G TOP SECTION 38.00  $           297.00
R-25AG5 EA 25G TOP SECTION 45.10  $           244.00
R-25GSSB EA 25G SELF SUPPORTING BASE PLATE 55.40  $           206.00
R-25TG EA 25G TAPERED BASE SECTION, 10'-0" 75.30  $        1,399.00
R-25TGIA EA 25G TAPERED BASE SECTION, 10'-0", A4197 76.20  $           979.00
R-25TDMKD EA 25G TOP DISH MOUNT 106.50  $           750.00
R-25AJBK EA 25AG JOINT BOLT KIT 0.40  $               3.20
R-25JBK EA 25G JOINT BOLT KIT 0.30  $               2.77
R-25GWM EA 25G WALL MOUNT 94.70  $           504.00
R-25RG EA 25G INSULATOR SECTION, 10'-0" 354.00  $        2,797.00
R-25ACL3 EA 25G ANTI-CLIMB PANELS (3) ONLY 99.20  $           406.00
R-2590FF EA 25G 90 DEGREE JOINTS, F-F 0.40  $           225.00
R-2590FM EA 25G 90 DEGREE JOINTS, F-M 9.70  $           244.00
R-2590MM EA 25G 90 DEGREE JOINTS, M-M 11.00  $           259.00
R-SR245 EA 25G & 45G SAFETY RING 8.00  $           324.00
R-ST25AG EA 25G TOP SECTION 5' 18.00  $           688.00
R-WP25G EA 25G WORK PLATFORM 10.00  $           165.00
R-SBH25G EA 25G HINGED SHORT BASE, 3'-4" 14.00  $           275.00
R-SDB25G EA 25G SINGLE DRIVE-IN BASE 20.00  $           220.00
R-SB25G EA 25G SHORT BASE, 3'-4" 10.00  $             83.00
R-SB25G5 EA 25G SHORT BASE, 5'-0" 19.00  $           120.00
R-RP25G EA 25G ROTOR POST 3.00  $             55.00
R-RP25GCM EA 25G SPECIAL ROTOR POST 2.00  $           141.00
R-TA25 EA 25G TORQUE ARM STABILIZER ASSEMBLY 35.00  $           308.00
R-TB25D EA 25G TORQUE BAR (Single Bar) 6.00  $             86.00
R-TB3 EA 25G, 45AG, 55AG HD THRUST BEARING 2.50  $           179.00
R-TB75 EA 25AG, 45AG TOWER BUSHING, 1.50" ID 0.50  $             22.00
R-UHF25G EA 25G SIDE ARM MOUNT 4.00  $             35.00
R-KY2068A15 EA MOUNT, SIDE ARM ASSY, FOR 25G, WITH 1.5" PIPE 23.00  $           137.00
R-KY2068A16 EA MOUNT, SIDE ARM ASSY, FOR 25G, WITH 1.66" PIPE 24.00  $           135.00
R-KY2068A2 EA MOUNT, SIDE ARM ASSY, FOR 25G, WITH 2.375" PIPE 32.00  $           150.00
R-APL25G EA 25G TOP BEACON PLATE 14.00  $           107.00
R-HB25AG EA 25G HOUSE BRACKET ASSY, ADJ 0" TO 15" 8.00  $           116.00
R-HB25BG EA 25G HOUSE BRACKET ASSY, ADJ 0" TO 24" 11.00  $           152.00
R-HB25CG EA 25G HOUSE BRACKET ASSY, ADJ 0" TO 36" 17.00  $           154.00
R-HBUTVRO EA 25G, 45G, 55G UNVL HD HOUSE BRACKET, 18-36" STANDOFF 38.10  $           260.00
R-BPC25G EA 25G CONCRETE BASE PLATE 27.00  $             75.00
R-BPH25G EA 25G HINGED BASE PLATE 21.00  $           256.00
R-BPL25G EA 25G TOP BEARING PLATE 12.40  $           212.00
R-D1130 EA 25G SIDE ARM MOUNT 70.00  $           285.00
R-D1230 EA 25G SIDE ARM MOUNT 90.00  $           306.00
R-D1330 EA 25G SIDE ARM MOUNT 70.00  $           247.00
R-D1430 EA 25G SIDE ARM MOUNT 75.00  $           302.00
R-DDM150 EA 25G DISH MOUNT 1.5" X 3' DBS 11.00  $           185.00
R-DDM166 EA 25G DISH MOUNT 1.66" X 3' DBS 15.00  $           203.00
R-DDM238 EA 25G DISH MOUNT 2.375" X 3' DBS 19.00  $           213.00
R-DM25G2 EA 25G FACE DISH MOUNT 42.00  $           230.00
R-EB2525G EA 25G UNIVERSAL EAVE BRACKET 7.80  $           105.00
R-EF2545 EA 25G & 45G TOWER ERECTION FIXTURE, 12' 20.40  $        1,096.00
R-P2545 EA POLE ONLY FOR EF2545 12.00  $           412.00
R-H2545 EA HEAD ONLY FOR EF2545 8.00  $           687.00
R-EP25343 EA EQUALIZER PLATE ASSY 25 3-HOLE 5.40  $             39.00
R-EP25345 EA EQUALIZER PLATE ASSY 25 5-HOLE 7.90  $             55.00
R-GA25GD EA 25G GUY BRACKET ASSEMBLY W/HARDWARE 14.00  $           134.00
R-GB25D EA 25G GUY BRACKET 1.5" X .25" 1.70  $             10.90
R-AS25G EA 25G TOP SINGLE ACCESSORY SHELF 4.00  $             59.00
R-BAS25G EA 25G ACCESSORY SHELF, W/TOP BRG, 1.5' 18.00  $           336.00
R-FR25G EA 25G BASE FOR FLAT ROOF MOUNT 24.00  $           373.00

Self Supporting 25G Tower Kits Wt. (lbs) Price (ea)
R-25SS010 EA 25G SELF SUPPORT TOWER KIT, NI, 10' 77.00  $           453.00
R-25SS020 EA 25G SELF SUPPORT TOWER KIT, NI, 20' 114.00  $           600.00
R-25SS030 EA 25G SELF SUPPORT TOWER KIT, NI, 30' 151.00  $           747.00
R-25SS035 EA 25G SELF SUPPORT TOWER KIT, NI, 35' 176.00  $           825.00
R-25SS040 EA 25G SELF SUPPORT TOWER KIT, NI, 40' 188.00  $           895.00

Bracketed 25G Tower Kits Wt. (lbs) Price (ea)
R-25BRKT040 EA 25G BRACKETED TOWER KIT, NI, 40' 254.80  $        1,338.00
R-25BRKT050 EA 25G BRACKETED TOWER KIT, NI, 50' 295.50  $        1,465.00
R-25BRKT060 EA 25G BRACKETED TOWER KIT, NI, 60' 336.20  $        1,598.00
R-25BRKT070 EA 25G BRACKETED TOWER KIT, NI, 70' 376.90  $        1,740.00
R-25BRKT080 EA 25G BRACKETED TOWER KIT, NI, 80' 417.60  $        1,880.00
R-25BRKT090 EA 25G BRACKETED TOWER KIT, NI, 90' 458.30  $        2,022.00
R-25BRKT100 EA 25G BRACKETED TOWER KIT, NI, 100' 487.00  $        2,110.00

Pre-Engineered 25 G guyed towers 70MPH Rev F - 90MPH Rev G Wt. (lbs) Price (ea)
R-25G90R040 EA 25G TOWER KIT, 90 MPH, NI, 40' 30.00  $        1,721.00
R-25G90R050 EA 25G TOWER KIT, 90 MPH, NI, 50' 302.60  $        2,227.00
R-25G90R060 EA 25G TOWER KIT, 90 MPH, NI, 60' 385.10  $        2,384.00
R-25G90R070 EA 25G TOWER KIT, 90 MPH, NI, 70' 433.40  $        2,541.00
R-25G90R080 EA 25G TOWER KIT, 90 MPH, NI, 80' 481.70  $        3,123.00
R-25G90R090 EA 25G TOWER KIT, 90 MPH, NI, 90' 569.70  $        3,287.00
R-25G90R100 EA 25G TOWER KIT, 90 MPH, NI, 100' 620.40  $        3,451.00
R-25G90R110 EA 25G TOWER KIT, 90 MPH, NI, 110' 671.20  $        3,615.00
R-25G90R120 EA 25G TOWER KIT, 90 MPH, NI, 120' 722.00  $        4,284.00
R-25G90R130 EA 25G TOWER KIT, 90 MPH, NI, 130' 835.10  $        4,454.00
R-25G90R140 EA 25G TOWER KIT, 90 MPH, NI, 140' 957.00  $        4,675.00
R-25G90R150 EA 25G TOWER KIT, 90 MPH, NI, 150' 899.60  $        5,284.00
R-25G90R160 EA 25G TOWER KIT, 90 MPH, NI, 160' 1,059.60  $        5,480.00
R-25G90R170 EA 25G TOWER KIT, 90 MPH, NI, 170' 1,122.90  $        5,663.00
R-25G90R180 EA 25G TOWER KIT, 90 MPH, NI, 180' 1,181.20  $        5,827.00
R-25G90R190 EA 25G TOWER KIT, 90 MPH, NI, 190' 1,231.90  $        6,030.00

Pre-Engineered 25 G guyed towers 90MPH Rev F - 110MPH Rev G Wt. (lbs) Price (ea)
R-25G110R040 EA 25G TOWER KIT, 110 MPH, NI, 40' 1,297.70  $        1,721.00
R-25G110R050 EA 25G TOWER KIT, 110 MPH, NI, 50' 302.60  $        2,227.00
R-25G110R060 EA 25G TOWER KIT, 110 MPH, NI, 60' 385.10  $        2,384.00
R-25G110R070 EA 25G TOWER KIT, 110 MPH, NI, 70' 433.40  $        2,541.00
R-25G110R080 EA 25G TOWER KIT, 110 MPH, NI, 80' 481.70  $        3,123.00
R-25G110R090 EA 25G TOWER KIT, 110 MPH, NI, 90' 569.70  $        3,287.00
R-25G110R100 EA 25G TOWER KIT, 110 MPH, NI. 100' 620.40  $        3,451.00
R-25G110R110 EA 25G TOWER KIT, 110 MPH, NI, 110' 685.20  $        3,615.00
R-25G110R120 EA 25G TOWER KIT, 110 MPH, NI, 120' 722.00  $        4,284.00
R-25G110R130 EA 25G TOWER KIT, 110 MPH, NI, 130' 835.10  $        4,468.00
R-25G110R140 EA 25G TOWER KIT, 110 MPH, NI, 140' 893.40  $        4,625.00
R-25G110R150 EA 25G TOWER KIT, 110 MPH, NI, 150' 941.70  $        5,746.00
R-25G110R160 EA 25G TOWER KIT, 110 MPH, NI, 160' 1,111.00  $        5,928.00
R-25G110R170 EA 25G TOWER KIT, 110 MPH, NI, 170' 1,239.40  $        6,822.00
R-25G110R180 EA 25G TOWER KIT, 110 MPH, NI, 180' 1,320.30  $        7,018.00
R-25G110R190 EA 25G TOWER KIT, 110 MPH, NI, 190' 1,383.50  $        7,194.00

Pre-Engineered 25 G guyed towers 110MPH Rev F - 130MPH Rev G Wt. (lbs) Price (ea)
R-25G130R040 EA 25G TOWER KIT, 130 MPH, NI, 40' 41.10  $        1,721.00
R-25G130R050 EA 25G TOWER KIT, 130 MPH, NI, 50' 302.60  $        2,227.00
R-25G130R060 EA 25G TOWER KIT, 130 MPH, NI, 60' 385.10  $        2,384.00
R-25G130R070 EA 25G TOWER KIT, 130 MPH, NI, 70' 433.40  $        2,541.00
R-25G130R080 EA 25G TOWER KIT, 130 MPH, NI, 80' 481.70  $        3,102.00
R-25G130R090 EA 25G TOWER KIT, 130 MPH, NI, 90' 572.20  $        3,300.00
R-25G130R100 EA 25G TOWER KIT, 130 MPH, NI, 100' 629.40  $        3,458.00

20 G Section Numbers, Parts and Accessories Wt. (lbs) Price (ea)
R-20AG EA 20G TOP SECTION, 9' 26.60  $           190.00
R-20BG EA 20G TOP SECTION, 3' 8.50  $           181.00
R-20G EA 20G STANDARD SECTION, 10'-0" 30.10  $           130.00





“Prices reflected in 2009 quotations are based on current steel cost and may or may not be appropriate at time of order placement. Based on current market volatility please confirm pricing at time of ordering.”

Contact Us

Order Form For ROHN Towers & Accessories

NOTE: THE PRICES FOR COMPLETE "GROUND" GUYED TOWERS AND INCLUDES ALL ITEMS LISTED ON THE PARTS LIST SHEETS. SEE GUY CHARTS AND PARTS LIST IN THE MASTER CATALOG FOR DETAILS. (NOTE: LOCAL ENGINEERS MUST BE CONSULTED TO DETERMINE ADEQUATE BASE AND ANCHOR DETAILS AND WIND LOADING CRITERIA FOR ALL ROOF TYPE INSTALLATIONS.

ANCHOR GROUNDING (AGK1G) AND BASE GROUNDING (BGK3G) ARE INCLUDED IN THE TOWER PRICES. HOWEVER, EXTRA COPPER WIRE MAY BE REQUIRED FOR ROOF INSTALLATIONS. SEE MAIN PRICE LIST FOR COPPER WIRE PRICES AND ORDER COPPER WIRE AS A SEPARATE ITEM.

INSTALLATION INFORMATION AND A SAFETY PACKAGE (PART NUMBER ACWS) ARE ALSO INCLUDED IN THE ABOVE TOWER PRICES. THIS PACKAGE CONSISTS OF ONE ANTI-CLIMB WARNING SIGN AND TWO DANGER-WATCH FOR WIRES LABELS ALONG WITH OTHER PRINTED SAFETY INFORMATION.
